Rocky Linux 9 配置时间同步服务 chrony

默认 Rocky Linux 9 已使用 chrony 时间服务,所以我们不需要再单独去安装 dnf install -y chrony,只需要配置对应的时间同步服务器即可。

NTP 服务器配置

vi /etc/chronyd.conf
# 添加阿里云NTP服务器
pool ntp1.aliyun.com iburst
pool ntp2.aliyun.com iburst
pool cn.pool.ntp.org iburst
# 允许指定网段访问此时间服务器,不然只允许本地网络
allow 172.16.0.0/16

# 设置时区为亚洲/上海
timedatectl set-timezone Asia/Shanghai

# 配置防火墙,也可以设置允许123/UDP端口
firewall-cmd --add-service=ntp
firewall-cmd --runtime-to-permanent

# 重启时间服务 & 查看服务启动状态
systemctl restart chronyd && systemctl status chronyd

# 设置开机自启动
systemctl enable chronyd

# 验证工作是否正常
[root@localhost ~]# chronyc sources
MS Name/IP address         Stratum Poll Reach LastRx Last sample
===============================================================================
^* 120.25.115.20                 2  10   347   815    -54us[  -65us] +/- 4415us
^- 203.107.6.88                  2  10   377   192  -5352us[-5352us] +/-   30ms
^- ntp5.flashdance.cx            2  10   245   725   -858us[ -858us] +/-  173ms
^- tock.ntp.infomaniak.ch        1  10   377   521  +1361us[+1361us] +/-  106ms
^- ntp.wdc1.us.leaseweb.net      2  10   375    91   +409us[ +409us] +/-  229ms
^- time.cloudflare.com           3  10   375   109  +1262us[+1262us] +/-  107ms

NTP 客户端配置

NTP客户端配置与服务器端配置基本相同,但是因为NTP客户端不需要接收来自其他主机的时间同步请求,因此不需要指定allow ***这行。
另外如果您的客户端不是 Rocky Linux 9,那么需要单独安装chrony服务。

# 安装chrony服务
dnf install -y chrony

# 就像`ntpdate`命令一样,我们可以使用`chronyd`命令手动将Linux服务器的时间与远程NTP服务器进行同步。
[root@outline ~]# chronyd -q 'server 172.16.11.141 iburst'
2022-12-02T06:55:47Z chronyd version 3.4 starting (+CMDMON +NTP +REFCLOCK +RTC +PRIVDROP +SCFILTER +SIGND +ASYNCDNS +SECHASH +IPV6 +DEBUG)
2022-12-02T06:55:47Z Initial frequency -9.614 ppm
2022-12-02T06:55:51Z System clock wrong by -0.000004 seconds (step)
2022-12-02T06:55:51Z chronyd exiting

# 配置服务器参数
vi /etc/chrony.conf
server 172.16.11.141 iburst

# 重启时间服务 & 查看服务启动状态
systemctl restart chronyd && systemctl status chronyd

# 设置开机自启动
systemctl enable chronyd

验证chrony的同步

# 在服务器端查看有哪些客户端通过此NTP服务器进行时钟同步
[root@localhost ~]# chronyc clients
Hostname                      NTP   Drop Int IntL Last     Cmd   Drop Int  Last
===============================================================================
172.16.11.188                 275      0  10   -  1076       0      0   -     -

# 验证系统时间是否已使用chrony同步
[root@outline ~]# chronyc tracking
Reference ID    : AC100B8D (172.16.11.141)
Stratum         : 4
Ref time (UTC)  : Fri Dec 02 07:01:43 2022
System time     : 0.000000019 seconds fast of NTP time
Last offset     : -0.000016983 seconds
RMS offset      : 0.000016983 seconds
Frequency       : 9.614 ppm slow
Residual freq   : -1.633 ppm
Skew            : 0.089 ppm
Root delay      : 0.006188698 seconds
Root dispersion : 0.001516752 seconds
Update interval : 2.0 seconds
Leap status     : Normal

# 检查chrony来源,列出有关chronyd使用的当前时间源的信息
[root@outline ~]# chronyc sources
210 Number of sources = 1
MS Name/IP address         Stratum Poll Reach LastRx Last sample
===============================================================================
^* 172.16.11.141                 3   6    37    39   +765ns[  +94us] +/- 4682us

# 列出有关chronyd使用的每个源的漂移速度和偏移估计的信息
[root@outline ~]# chronyc sourcestats  -v
210 Number of sources = 1
                             .- Number of sample points in measurement set.
                            /    .- Number of residual runs with same sign.
                           |    /    .- Length of measurement set (time).
                           |   |    /      .- Est. clock freq error (ppm).
                           |   |   |      /           .- Est. error in freq.
                           |   |   |     |           /         .- Est. offset.
                           |   |   |     |          |          |   On the -.
                           |   |   |     |          |          |   samples. \
                           |   |   |     |          |          |             |
Name/IP Address            NP  NR  Span  Frequency  Freq Skew  Offset  Std Dev
==============================================================================
172.16.11.141               6   5   136     +0.306      3.073    +11us    42us

# 默认情况下,NTP 客户端每64秒执行一次时间同步。但是,您可以手动调整时钟而无需等待下一次同步轮询。
[root@outline ~]# chronyc makestep
200 OK
